The ultra-compact dimensions of the Ecosoft Arctic Blue series utilising the Clack® CE valve make these softeners both space-saving and reliable. The compact design is combined with high flow and softening capacity due to the unique 10×18 mineral tank size, it fits easily under the kitchen sink.

Made in Belgium with 100% US-made equipment
Fits up to 117 kgs of salt - 9 months till next salt refill
Smart overflow location saves installation space and protects against mechanical damage
Ecosoft Clack WS1 CE Valve (time and volume regenerated).
DOWEX® HCR-S/S — provides softened water. Arctic Blue series filters remove hardness.

Components:
Pre-adjusted US-made Clack® CE valve
Cabinet enclosure
Pressure tank
Brine well with safety float valve
Ion-exchange resin DOWEX™ HCR-S/S

Technical specifications
Operating Flow rate — 0.8 m³/h (Max - 1.0m³/h)
Quantity of media — 12 L
Volume capacity* — 2.4m³
Usage of salt per regeneration** — 1.2 - 1.9 kg
Usage of water per regeneration — 0.12 m³
Duration of regeneration — 80–110 minutes
Pressure drop in service mode — 0.5 bar
Inlet pressure — 2–6 bar
Electrical requirements — 230 V, 50 Hz
Power consumption — 30 W
Inlet/outlet pipe connections — 1"
*for hardness at 5 meq/L (250 mg/L CaCO₃)
**it is recommended to use Ecosil pelletized salt for regeneration

Influent water limitations
Hardness — 15 meq/L (750 mg/L CaCO₃)
Iron — 0.2 mg/L
Manganese — 0.05 mg/L
Required level of purification of sediment particles — 100 μm
Initial water temperature — +4…+30 °С

Manufacturer Link: https://www.ecosoft.com/product-ecosoft/ecosoft-fu1018cabce
